冲压外圈滚针离合器和轴承组件 |
HFL |
HFLZ英制 |
HFL,HFLZ |
nmousewheel="return bbimg(this)" onload="javascript:resizepic(this)" border="0">
nmousewheel="return bbimg(this)" onload="javascript:resizepic(this)" border="0">轴径 | 轴承型号 | 主 要 尺 寸 | 传动力矩 | 极限转速* | 基本额定负荷 | ||||
FW | D | C | n | nl** | C | Co | |||
mm | mm | Nm | rpm | N | |||||
4 | HFL0408 | 4 | 8 | 8 | 0.34 | 34000 | 14000 | 1270 | 1740 |
6 | HFL0615 | 6 | 10 | 15 | 1.76 | 23000 | 13000 | 1650 | 2030 |
8 | HFL0822 | 8 | 12 | 2 | 3.15 | 17000 | 12000 | 4050 | 4150 |
10 | HFL1022 | 10 | 14 | 22 | 5.3 | 14000 | 11000 | 4300 | 4650 |
12 | HFL1226 | 12 | 18 | 26 | 12.2 | 11000 | 8000 | 6300 | 6500 |
14 | HFL1426 | 14 | 20 | 26 | 17.3 | 9500 | 8000 | 6300 | 6500 |
16 | HFL1626 | 16 | 22 | 26 | 20.5 | 8500 | 7500 | 7300 | 8400 |
18 | HFL1826 | 18 | 24 | 26 | 24.1 | 7500 | 7500 | 8200 | 10300 |
20 | HFL2026 | 20 | 26 | 26 | 28.5 | 7000 | 6500 | 8300 | 10400 |
25 | HFL2530 | 25 | 32 | 30 | 66 | 5500 | 5500 | 10900 | 14100 |
30 | HFL3030 | 30 | 37 | 30 | 90 | 4500 | 4500 | 12600 | 17600 |
35 | HFL3530 | 35 | 42 | 30 | 121 | 3900 | 3900 | 13000 | 19300 |
3/8 | HFLZ061014 | 9.525 | 15.875 | 22.22 | 50.4 | 14000 | 12000 | 1315 | 1240 |
1/2 | HFLZ081214 | 12.7 | 19.050 | 22.22 | 85.9 | 11000 | 9000 | 1720 | 1550 |
5/8 | HFLZ101416 | 15.875 | 22.225 | 25.4 | 175.2 | 8500 | 5000 | 1720 | 1890 |
